INDUSTRIAL FURNACE DIVISION
FLAMELESS TYPE
Standard specifications of batch type furnace (PUSHER type: DNR11, ROLLER type : DNR22 series)
| Effective Size (mm) | Heater (Kw) | ||||||
|---|---|---|---|---|---|---|---|
| Model | Width | Length | Height | Capacity | Furnace | Oil Tank | Remarks |
| DNR11-203618Q | 510 | 915 | 455 | 320 | 40 | 36 | CUSTOM FURNACE WHEN NEEDED |
| DNR11-244824Q | 600 | 1,230 | 600 | 550 | 80 | 48 | |
| DNR11-264826Q | 660 | 1,230 | 650 | 650 | 90 | 48 | |
| DNR11-304826Q | 760 | 1,230 | 650 | 750 | 100 | 54 | |
| DNR11-304828Q | 760 | 1,230 | 700 | 850 | 110 | 54 | |
FURNACE FEATURE
- Batch Type Furnace
- Easy quality control, High relaiability
- High energy efficiency, Full Automatic
- Easy control and maintenance
PROCESS OPTIONS
- Carburizing, Carbonitriding, Bright Quenchinq, Annealinq
